AD Office Boway NCC330 china creasing machine

AD Office Boway NCC330 china creasing machine

  • Modelo: NCC330
  • Precio FOB:USD 4200.00-4500.00 / unidad
  • Pedido mínimo:1 unidad
  • Aceptar el pedido mínimo:Yes
  • Disponibilidad:500 unidad / El
  • Lugar original de origen:Shanghai/Ningbo
  • Plazo de entrega:In 15 days after payment De
  • Place of Origin:CN;ZHE
  • Warranty:At least 1 year
  • After-sales Service Provided:Engineers available to service machinery overseas
  • Condition:New
  • Voltage:220V/110V (optional)
  • Dimension(L*W*H):870*570*1070mm
  • Weight:80 kg
  • Model Number:NCC330
  • Computerized:
  • Type:AD Office Creasing Machine

since1996BANNER780

******The pricture and specifications are subject to change without prior notice. ******

******Any question, please confirm with our sales manager.******

Welcome  to  Boway

Core Competence

HTB1SG5WGVXXXXbuXFXXq6xXFXXXy

We provide more than 300 kinds of office equipment for your need

(You may click the following picture to see more)


How  to  Choose  Your  Right  Items?

Product Uses
Paper Creasing,Spining & Hingling,folding,Perforating
NCC330is a digital controlled creasing system which has both creasing and perforating function. It’s designed for digital printing and On-demand printing users.

The Touchable colour LCD screen allows the operator to read, edit, create and initiate numerous creasing programs within the memory. Up to 10 creases can be programmed to a single sheet.

It is capable of creasing paper up to 400gsm, including laminated material, and the crack of the printed sheets was eliminated by the professional creasing design principle and excellent mechanical control design.

Appearance


Specification Param



Model No.

NCC330

Max. sheet size

330mmx 990mm

Min. sheet size

140mmx 160mm

Paper thickness

80~400 g/m²

Max. number of creases/sheet

10

Max. speed

About 4000 creases/hour

Min. crease distance

0.1 mm

Power supply

220V/110V (optional)

Machine Weight

80 kg

Machine dimensions

870×570×1070mm

Advantages Details

 Servo control system makes the high-accuracy creasing and reliably running.

 It’s more stable and accurate than singlechip system. Avoid the missing step which caused by stepping motor and ensure the accurate creasing position.

 Centered high speed optical fiber detection makes the reaction speed much faster.

 Adjustable paper feed table, external micromatic setting, adjust the centered position and slant position by revolving the adjusting knob.

 A3 & A4 folio parameter preset, paper size, number of crease and creasing position can be set as needed.

 Two modularization opposing creasing grooves optimize the creasing result and avoid the paper crack.

 Breadthwise creasing and lengthways perforating can work synchronously. The running speed and pressure of the blade can be adjusted. (Perforator is optional accessory.)

 Touchable colour LCD screen allows the operator to set the crease positions and the number of creases. It also shows the stored programs as well as the counting date.

 User friendly vertical worktable, self-locking truckles, easy to move and settle down.

 Speeds up to 4000 creases per hour (depending on operator).

 Maximum sheet size: 330×990mm.

Package & Shipment

Trading Terms

Terms of paymentT/T, L/C, Westion Union.
Terms of tradeFOB, CFR, CIF
Mode of transportationBy Sea,  By Air
Port of shipmentShanghai or Ningbo
Rerfence date of delivery

About 15 days, Instant supply

of hot-selling products

About Shipment

Certificate of Fumigation
Certificate of Original

CO, FORM A, FORM F, FORM E etc.

Guarantee customer to import goods

at the preferential tariff rate

Certificate of Inspection
Documents Authentication


After-Sales Service

I. Agents Tranining


II. Warranty

We provide one-year limited warranty for all machines from the date of purchase

1. Our warranty covers only those defects which arise as a result of normal use of the product, and the bellows not apply to any:

u       Improper or inadequate maintenance

u       Misusage and mishandling

u       Damaged by a wrong voltage use

u      Physical damage(for example, dropping the parts on the floor or into water, broken case, etc)

2. What is the repair, exchange & refund policy?

Exchange and refund only on big defective units (beyond repair).For buyers' used machines, we only can support repair service.

Repair: We provide free spare parts (just include the main board and motor) within the warranty period. Buyer should provide serial number and photos of defective machines, but buyer should pay the shipment charges and return us the broken parts.

Exchange: If you reported problem to us in one month on arrival of the machine, we accept the exchange. Buyer needs pay the ship back sea freight and the sea freight for new machine.

Refund: If you reported problem to us in one week on arrival of machines, we accept the refund, but we only refund you the payment after receiving the returned goods.

3. What about when one year warranty over time?

We still offer the repair service to you when the warranty time is over, even we can offer you the repair service in the whole life of machine.

4. How to support you when you purchase our machine in first time?

When you meet the problem of our machine under the situation that you are not familiar with our machines.

Do not worry, we can offer:

u        User Manual in English

u        Operation Video

u         Support on-line

u        You can send your technician to our factory to attend the skill training.

Customers  and  Us


FAQ

1.What’s the product range?

   Post press machine,such as Perfect glue binder, paper cutter, Roll laminator, UV coator machine and some small office equipment.

2.Are you a manufacture?

   Yes, we are in Hangzhou which middle of shanghai and Ningbo

3.What is the minimum quantity for order?

   5 pcs or 10000 USD for order.

4.Do you have stock product to sell?

   Maybe , It’s depend on which machine ,you like?

5.Do you inspect the finished products?

   Yes, Each step of production products will be camed out inspection by QC department before shipping.

6.How do you ship the finished products?

   By Sea

  By Plane

  By courier, TNT , DHL, Fedex, UPS Etc

7.What’s the Payment term?

   Payment term: T/T before shipment.

   We accept payment via the Paypal /Western union/TT, you can choose as you like.

8.What’s the delivery time?

   Within 15 days after get the payment
